LDAP and Active Directory

PhotoPrism® Pro lets you authenticate users against a central Lightweight Directory Access Protocol (LDAP) or Active Directory (AD) server so that users on the corporate network can sign in with their existing usernames and passwords. See Environment Variables and CLI Flags for more information on the configuration options.

Config Options

Docker Compose Example

services:
  photoprism:
    ...
    environment:
      ## LDAP Authentication
      PHOTOPRISM_LDAP_URI: "ldaps://ldap.example.com:636"
      PHOTOPRISM_LDAP_INSECURE: "false"
      PHOTOPRISM_LDAP_SYNC: "true"
      PHOTOPRISM_LDAP_BIND: "simple"
      PHOTOPRISM_LDAP_BIND_DN: "userprincipalname"
      PHOTOPRISM_LDAP_BASE_DN: "dc=example,dc=com"
      PHOTOPRISM_LDAP_ROLE: ""
      PHOTOPRISM_LDAP_ROLE_DN: "ou=photoprism-*,ou=groups,dc=example,dc=com"
      PHOTOPRISM_LDAP_NOLOGIN: "false"
      PHOTOPRISM_LDAP_WEBDAV: "true"

Server URI & Certificate

The URI of the LDAP or Active Directory server must be specified in the format ldap://hostname:port for plain LDAP and ldaps://hostname:port for LDAPS (LDAP over SSL). For this, the default ports are 389 (LDAP) and 636 (LDAPS).

If the directory server does not have a certificate signed by a trusted certificate authority, you can either set PHOTOPRISM_LDAP_INSECURE to true to ignore SSL certificate errors, or trust a self-signed certificate by specifying a .pem file in the /config/certificates storage folder with PHOTOPRISM_LDAP_CERT.

User Bind DN

The Bind DN (Distinguished Name) is used to identify your account when you authenticate through the LDAP/AD directory server. PhotoPrism also uses it in combination with the Base DN to retrieve and synchronize user attributes such as the email address, display name, and role, if specified. It is usually set to the Common Name (CN) of the account or the UPN (UserPrincipalName) in Active Directory, which is an email-like identifier such as user@example.com. However, UPNs don’t necessarily require a valid domain.

Directory Base DN

The Base DN is the starting point when searching for users within the directory. It is commonly set to the domain components (DC) of your organization, for example dc=example,dc=com.

Specifying User Roles

The default role for users authenticated via LDAP/AD can be specified with PHOTOPRISM_LDAP_ROLE.

You can additionally specify a custom role attribute with PHOTOPRISM_LDAP_ROLE_DN, for example photoprismrole. To indicate the role, you can then map the attribute to the name of a valid role in lowercase, for example photoprismrole="viewer". Note that the attribute name is not case sensitive, but the values should be lowercase, e.g. admin, true or false.

Alternatively, you can specify a group DN in PHOTOPRISM_LDAP_ROLE_DN and use * as a placeholder for the role name, e.g. ou=photoprism-*,ou=groups,dc=example,dc=com.

Learn more chevron_right

Custom Attributes

Additional custom user attributes can be specified with the PHOTOPRISM_LDAP_NOLOGIN_DN, PHOTOPRISM_LDAP_WEBDAV_DN, PHOTOPRISM_LDAP_BASE_PATH_DN and PHOTOPRISM_LDAP_UPLOAD_PATH_DN config options. Note that attribute names are not case sensitive in LDAP.

Instead of only providing an attribute name in PHOTOPRISM_LDAP_NOLOGIN_DN and PHOTOPRISM_LDAP_WEBDAV_DN, you can alternatively specifiy a key and value like primaryGroupID=500.

Command-Line Tools

Troubleshooting

To test the connection to your LDAP/AD server, view user attributes, and troubleshoot problems, you can use the built-in ldap search subcommand, as shown in this example:

docker compose exec photoprism photoprism ldap search -D bob@example.com cn=bob

Users of Red Hat-based Linux distributions can substitute Docker with Podman:

podman-compose exec photoprism photoprism ldap search -D bob@example.com cn=bob

You can combine it with these flags to change the output format, the maximum number of search results and the credentials used for authentication:

If you need additional authentication or query options, we recommend using the freely available ldapsearch command, which is included in most Unix-like operating systems as part of the LDAP utilities package.

User accounts authenticated with LDAP/AD can be searched with the following command:

docker compose exec photoprism photoprism ldap ls

Viewing the Current Config Values

To view the current values of all config options, you can run the following:

docker compose exec photoprism photoprism show config

To display all supported config options and their default values:

docker compose exec photoprism photoprism show config-options
